Fitur :
- Teknologi IPAL untuk kemudahan pengolahan air limbah
- Ramah lingkungan
- Dilengkapi dengan unit Bio Reactor System
- Instalasi lengkap untuk pengolahan maksimal dan menyeluruh
Spesifikasi :
| ● | PRE TREATMENT EQUALISASI | ||
| - Material | : | Brick Wall Acian | |
| - Dimensi | : | P x L x T = 800mm x 800mm x 1400mm | |
| - Finishing | : | Fiber Lining | |
| - Setting | : | Terpasang dan berfungsi dengan baik | |
| ● | UNIT PENGOLAHAN UTAMA BIOREACTOR SYSTEM | ||
| - Volume | : | 2,5m3 | |
| - Type | : | Bioreactor aerobic treatment | |
| - Material | : | Mild Steel | |
| - Finishing out | : | Epoxy Marine Coating | |
| - Dimensi | : | 1200mm x 1200mm x 1500mm | |
| - Compartement | : | 1Compartement | |
| - Piping | : | PVC AW 4" | |
| - Acsesoris | : | Fine Buble Diffucer non Clogging | |
| CLARIFIER SYSTEM | |||
| - Volume | : | 2m3 | |
| - Material | : | Fibre Reinforce Plastic | |
| - Finishing out | : | Epoxy Marine Coating | |
| - Dimensi | : | 1200x1200 X 1500 mm | |
| - Compartement | : | 1Compartement | |
| - Piping | : | PVC AW 4" | |
| - Acsesoris | : | Central Tube, weir and gutter | |
| - Setting | : | Terpasang dan berfungsi dengan baik | |
| TREATED WATER TANK | ||
| - Volume | : | 1300 Liter |
| - Material | : | HDPE |
| - Compartement | : | 1Compartement |
| - Piping | : | PVC AW 4" |
| - Acsesoris | : | Central Tube, weir and gutter |
| - Setting | : | Terpasang dan berfungsi dengan baik |
| ● | BASIC FILTRATION EQUIPMENT SAND FILTER | ||
| - Material | : | FRP | |
| - Dimensi | : | Ø 300mm T. 1800mm | |
| - Farmiting flow | : | 10 m3/hr at flow | |
| - High Filtering | : | 800mm | |
| - Working Pressure | : | 2.5 Bar | |
| - Testing Pressure | : | 5 kg/cm2 | |
| - Piping conection | : | 50 mm | |
| - Finishing in FRP | |||
| - Totally anti corrosive even restent to | |||
| - Ball valve PVC 5 unit | |||
| - Indicating pressure gauges | |||
| - Interconecting pipe galvanized | |||
| - Media Silica sand ex bangka | |||
| - Setting | |||
| CARBON FILTER | ||
| - Material | : | FRP |
| - Dimensi | : | Ø 300mm T. 1800mm |
| - Farmiting flow | : | 10 m3/hr at flow |
| - High Filtering | : | 800mm |
| - Working Pressure | : | 2.5 Bar |
| - Testing Pressure | : | 5 kg/cm2 |
| - Piping conection | : | 50 mm |
| - Finishing in FRP | ||
| - Totally anti corrosive even restent to | ||
| - Ball valve PVC 5 unit | ||
| - Indicating pressure gauges | ||
| - Safety valve Acsesoris | ||
| - Media activated carbon | ||
| - Setting | : | Terpasang dan berfungsi dengan baik |
| ● | PEKERJAAN MECHANICAL & ELECTRICAL POMPA INTAKE EQUALISASI | |||
| - Material | : | Stainless stell | ||
| - Type | : | Submersible Pump | ||
| - Kapasitas | : | 5 m3 / jam ( Kebutuhan Operasi ) | ||
| - Total Head | : | 10 m | ||
| - Power | : | 1/2 HP / 1 phase / 280 V | ||
| - Acsesoris | : | Water level Control | ||
| - Piping | : | 1 " PVC AW | ||
| - Setting | : | Terpasang dan berfungsi dengan baik | ||
| TURBOJET SURFACE AERATOR (Optional)* | ||||
| - Material | : | Stainles Steel | ||
| - Power | : | 1 HP / 3 phase / 280 V | ||
| - Setting | : | Terpasang dan berfungsi dengan baik | ||
| BLOWER (Optional ) * | ||||
| - Model | : | Diaghpramp | ||
| - Operation | : | Manual | ||
| - Header and distribution valve | ||||
| * Disesuaikan dengan ketersedian listrik/tegangan di lokasi (1 phase/3 phase) | ||||
| FILTER PUMP & RAS PUMP | ||
| - Material | : | Cast Iron |
| - Type | : | Centrifugal |
| - Kapasitas | : | 5 m3 / jam ( Kebutuhan Operasi ) |
| - Total Head | : | 10 m |
| - Power | : | 0,5 HP / 1 phase / 220 V |
| - Acsesoris | : | Water level Control |
| - Piping | : | 3/4 " PVC AW |
| - Setting | : | Terpasang dan berfungsi dengan baik |
| DESINFECTAN SISTEM | ||
| - Material | : | PVC AW |
| - Type | : | Contac Injector Circulated |
| - Dimensi | : | Ø 2" P. 50cm |
| - Contac Media | : | 2 m3/jam |
| - Setting | : | Terpasang dan berfungsi dengan baik |
| ELECTRICAL | ||
| - Panel | : | Semi Automatic |
| - Type | : | Out Door And Double Door |
| - Wire | : | 4 bigest |
| - Acsesoris | : | 4 Tray cable |
| - Setting | : | Terpasang dan berfungsi dengan baik |
| PIPING | ||
| - Material | : | PVC |
| - Type | : | AW |
| - Valve | : | Ball Valve PVC |
| - Acsesoris | : | Fiting fitting all size |
| - Dimensi | : | 3/4" - 2" |
| - Setting | : | Terpasang dan berfungsi dengan baik |
| PEKERJAAN PENDUKUNG |
| - Pengadaan bahan kimia masa Comissioning |
| - Training Include |
| - Install |
| - Comissioning |
| OPTIONAL |
| - Pekerjaan Pondasi, Atap (Bentuk Menyesuaikan) |
| ● | Hasil laboratorium sesuai dengan yang ditunjuk oleh PT. Indo Tekhnoplus | |
| ● | Daily measurment outlate with pH Meter | |
| Digital Water Tester | ||
| Calibration | : pH up to 5 points; TDS Up to 3 (manual) | |
| Resolution & Accuracy | : 0.01 :pH;± 0.01 pH | |
| 0.1 ppm / 1 ppm / 0.01 ppt; ± 1% | ||
| EHIS Compatibel | : Yes | |
| Operating Temperature | : -5 to 55 ˚C | |
| Supply With : | |
| ● | Instructions Manual (bahasa Indonesia) |
| ● | Telah memperoleh sertifikat ISO 9001:2008 |
| ● | Telah memperoleh sertifikat ISO 14001:2004 |
| ● | Telah memperoleh sertifikat OHSAS 18001:2007 |
Environtmental and Health Integration System (EHIS)
