Fitur :
| Spesifikasi | |||||||||||
| pH | mV | ||||||||||
| › | Range | : | -2… +16 pH | › | Range | : | ±2000 mV | ||||
| › | Resolution | : | 0.001 pH | › | Resolution | : | 0.1 mV | ||||
| › | Accuracy | : | 0.1& ± 1 digit | › | Accuracy | : | 0.1% ± 1 digit | ||||
| › | Calibration | : | 1…5 points | › | Calibration | : | 1 point | ||||
| › | Buffer | : | 9 pre-programmed 5 user spectifled | ||||||||
| › | Temprature compensation: -30… + 130°C | Resistivity | |||||||||
| › | ISO-pH | : | 6…8 pH | › | Range | : | 0… 200mΩ. Cm | ||||
| › | slope | : | 80… 120% | › | Resolution | : | 1Ω. Cm | ||||
| › | zero point (Eo) | : | ±999 mV | ||||||||
| Dissolved Oxygen | Salinity | ||||||||||
| › | Range | : | 0… 60mg (0…600%) | › | Range | : | 0… 70ppt | ||||
| › | Resolution | : | 0,01 mg/ (0.1%) | › | Resolution | : | 0,1 ept | ||||
| › | Accuracy | : | 1% ± 1 digit | ||||||||
| › | Calibration | : | 1 point | TDS | |||||||
| › | Temperature Compensation | : | 0…50°C | › | Range | : | 0…100g/1 | ||||
| › | Salinity compensation | : | 0…40ppt | › | Resolution | : | 0,01 mg/ 1 | ||||
| › | Air pressure compensation | : | 600… 1300hPa | ||||||||
| Temperature | |||||||||||
| Conductivity | › | Range | : | 30… +130°C | |||||||
| › | Range | : | 0…2000 rnS / cm | › | Resolution | : | 0.1°C | ||||
| › | Resolution | : | 0.001 uS / cm | › | Accuracy | : | 0.3°C | ||||
| › | Accuracy | : | 0.5% f. s. of range | › | Calibration | : | 1 point | ||||
| › | Calibration | : | 1…3 points | ||||||||
| › | Standards | : | 0.01/0.1/1M KCI 3 User specifled | Air Pressure | |||||||
| › | Cell constant | : | 0.05…15.0 cm | › | Range | : | 600…. 1300hPa | ||||
| › | temprature compensation | : | -30… +130°C | › | Calibration | : | 1 point | ||||
| › | Reference temperature | : | 20° - 25 °C | ||||||||
| › | Temperature coefficient | : | natural waters (en 27888) | Input | |||||||
| › | Range lock | : | P | › | Measurement | : | BNC, 10² Ω | ||||
| › | Capacitive compensation | : | P | › | Temperature | : | 2 banana, for pt 1000 | ||||
| ● | Display | : | LCD 128 x 64 pixel, Whitebacklight, hold function, selectable resolution, |
| Real time clock | |||
| ● | Language | : | Bahasa Indonesia, English , Nederlands, Francais, Deutsch |
| ● | Analog Output | : | Recorder 0 - 2 V1 programmable |
| ● | RS232 | : | Interface with printer or PC, Baud Rate: 300 - 19200 b/s |
| ● | Data logging | : | |
| - Values | : | 3600+°C /date/ time | |
| - Modes | : | all | |
| - Manual or timed | : | P | |
| - Interval | : | all…9999 s | |
| ● | Security | : | Indectification number & Password protection |
| ● | Ambient conditions | : | Temperature 0 - 40° C, humidity 0 - 95% non condensing |
| ● | Power Supply | : | Mains 210 - 250 VAC, 50/60 Hz, low voltage 9 - 15 VDC, baterai 4x1.2 V, NiMH |
| ● | Komunikasi Perangkat | : | NFC |
| ● | Dimention | : | WxDxH 12x25x5 cm |
| ● | Weight | : | 600 g |
| ● | Include supply | : | Meter kit complete : C6010 + pH/ATC electrode + Conductivity/ATC electrode + |
| Dissolved Oxygen electrode + 2x50 ml buffers (pH 4 and 7) + 50 ml electrolyte (3M KCl) | |||
| + 50 ml Conductivity standard (0,01 M KCl) + Carrying Case, EHIS V2 | |||
| ● | Manual Book | : | Bahasa Indonesia & Bahasa Inggris |
| ● | Telah memperoleh sertifikat ISO |
