Tags: HAZDUST, Analisa Kualitas Udara,
• | Display | : | Large Alphanumeric LCD-4 line, 20 character display | |||||||||||||||||||||||||||||||||
• | Operation | : | Four key splash proof membrane switch - menu driven | |||||||||||||||||||||||||||||||||
• | Calibration | : | Gravimetric reference NIST traceable - SAE fine test dust | |||||||||||||||||||||||||||||||||
• | Accuracy | : | ± 10% to filter gravimetric SAE fine test dust | |||||||||||||||||||||||||||||||||
• | Sensing range | : | .001-20.0 mg/m³ or .01 - 200.0 mg/m³ (optional) | |||||||||||||||||||||||||||||||||
• | Particulate size range | : | .01 - 100 µm | |||||||||||||||||||||||||||||||||
• | Precision | : | ± .003 mg/m³ (3 µg/m³) | |||||||||||||||||||||||||||||||||
• | Sampling flow rate | : | 1.0 - 5.0 liters/minute | |||||||||||||||||||||||||||||||||
• | Filter cassette | : | 47mm FRM style | |||||||||||||||||||||||||||||||||
• | Alarm output | : | 90db at 3 ft | |||||||||||||||||||||||||||||||||
• | Recording time | : | 1 second to 15 months | |||||||||||||||||||||||||||||||||
• | Sampling rate | : | 1 second, 10 seconds, 1 minute, and 30 minutes | |||||||||||||||||||||||||||||||||
• | Data storage | : | 21, 600 data points | |||||||||||||||||||||||||||||||||
• | Memory & time storage | : | >5 years | |||||||||||||||||||||||||||||||||
• | Real-time clock & display | : | Hours, Minute, Second, Day, Month, Year | |||||||||||||||||||||||||||||||||
• | Data display | : | Concentration range in mg/m³ & TWA, MAX, MIN, STEL, Date, Time | |||||||||||||||||||||||||||||||||
• | Digital output | : | RS-232 | |||||||||||||||||||||||||||||||||
• | Operation temperature | : | -10°C to 50°C | |||||||||||||||||||||||||||||||||
• | Storage temperature | : | -20°C to 70°C | |||||||||||||||||||||||||||||||||
• | DustComm Pro Software | : | Windows driven for graphical and data translation | |||||||||||||||||||||||||||||||||
• | Power | : | Rechargeable and interchangeable battery Operating time:>24 hours | |||||||||||||||||||||||||||||||||
on battery | ||||||||||||||||||||||||||||||||||||
• | Charging time | : | Approximately 22 hours | |||||||||||||||||||||||||||||||||
• | Humidity | : | 95% non-condensing | |||||||||||||||||||||||||||||||||
• | Dimensions (case) | : | 14.0" x 6.0" x 10.0" | |||||||||||||||||||||||||||||||||
• | Weight | : | 12 lbs. | |||||||||||||||||||||||||||||||||
• | Supply With : | |||||||||||||||||||||||||||||||||||
Carrying case, battery charger, TSP impactor sleeve, impactor dust seal, FM015 Flow Audit Meter, and HAZ_DUST | ||||||||||||||||||||||||||||||||||||
Media CD-ROM which includes the instruction manual and DustComm Pro Software, compatible with Windows 7 and | ||||||||||||||||||||||||||||||||||||
XP, Kartu Garansi, Manual Bahasa Indonesia, EHIS (Environment and Health Integration System) |
